Power (kw): 7.5/11/15/18.5
Input voltage: 380V / 50HZ
Output rotate scope: 0~4000rpm
Testing cylinder number: 12 jar
Principle Axis center high: 125 mm
Working table high: Common type 820 mm / wide 850mm
Standard fuel injector: bearing pin / Pore plate/ Low inertia hole plate
Fuel injector opening pressure: 17.5±0.2 MPa
Computer configuration: flushbonading/PC104 system
Display: LED/CRT/LCD
Fuel tank volume: 60 L
Rotate preset quantity: 7~10
Oil number counting: 0~1000 St
Small measuring cylinder volume: 45 ml
Oil return measurement cylinder volume: 500 ml
Oil supply low pressure: 0~0.4 Mpa
Testing oil supply flow: ≥10 L/Min
